Air Systems International CO2-91PM CO2 Monitor Complete For Panel
Air Systems International CO2-91PM CO2 Monitor Complete For Panel
Features
Control Panel Standard Features:
- Inlet gas quick connect coupling
- Auxiliary 12 VDC jack
- On/off/test switch
- Auxiliary/remote alarm jack
- 115 VAC jack
Specifications
CO Monitor Specifications:
Calibration: Less than 2 minutes
Monitor display: LCD 3-digit readout
Temperature range: 4 to 113 degrees F (-20 to 45 degrees C)
Accuracy: +1- 1 % of full scale
Monitor range: 0-200 ppm CO (15-23% for optional 0,)
Pressure range: 1-3 psi, flow 50-100cc
Response: 90% of full scale in 10 seconds
Sensor type: 3-electrode electrochemical with bias voltage
Humidity range: 5% to 95% relative humidity
Warranty: 2 years on entire unit and CO sensor (1 year on oxygen sensor)
Alarm set point: 10ppm CO (5 ppm Canada)
Voltage operation: 115 VAC, dual 9-volt DC battery, or 8-1 6 volt DC
Test circuitry: manual push-to-test for sensor operation and alarms
Shielding: internal RFI/EMI circuitry, aluminum case
Warning indicators: low battery (amber), normal operation (green), high CO level (red) (LED indicators vary with model ordered)
Output signals (standard): DC output on portables, AC output on panel versions
Monitor case housing: black anodized aluminum
Dimensions: 7.0" Lx 2.75" H x 5.1" W
Weight: 2.1 lbs.
