Air Systems International BB100-CO2PM Breathing Air Panel

Original price $3,195.00 - Original price $3,195.00
Original price
$3,195.00
$3,195.00 - $3,195.00
Current price $3,195.00

Air Systems International BB100-CO2PM Breathing Air Panel

The Air Systems BB100-CO2PM is a Grade-D filtration system to supply breathing air for a specific amount of workers.

The BB100-CO2PM system filters the incoming air from your compressor to supply respirators with Grade D quality air while monitoring for Carbon Monoxide and Oxygen levels.

The 1st stage element will filter bulk water & particulate. The 2nd stage is a coalescing filter that eliminates ultra-fine particulates, mists & atomized oils. The 3rd stage filter will remove organic vapors & odors. The filter change indicator is standard for all 3 filtration stages. The efficiency of filtration is 99.99 percent at .01 micron.

A built-in carbon monoxide (CO) monitor operates with 9 Volt DC, 115 Volt AC, or 8 to 16 VDC providing continuous detection. The audible high-intensity alarm & light alert workers to high carbon monoxide content in the breathing air supply. A 115 Volt AC conduit box (included) provides power in & connections for remote AC-powered alarms. The filtration components come mounted on a powder-coated steel panel.

* When ordering, please specify .25 inch Hansen or Schrader style fittings

  • All fixed and portable breathing air filtration systems exceed or meet Breathing Air Standards
  1. OSHA 1910.134
  2. Canadian Z180.1
  • British BS-EN 12021:1999 Standard - RESPIRATORY PROTECTIVE DEVICES
  • All units are designed to flow NIOSH max. capacity per worker
  • Air Systems will provide your 1st lab-certified (at NO CHARGE) air quality test for your new filtration device.

Features

  • 4 couplings or NPT outlet
  • Electrical conduit box - 115 VAC
  • Standard indicators for filter change for all three filtration stages
  • Filtration efficiency - 99.99% @ .01 micron
  • Meets OSHA 1910.134
  • 100 cfm flow capacity, 123 cfm with CO monitor
  • The Air Systems BB100-CO2PM Breathing Air Panels- 1 comes equipped with a filter change indicator.

Benefits

  • High performance
  • Quick and easy stages for air filtration
  • Durable construction
  • 2 year monitor and sensor warranty

Resources

Air Systems BB100-CO2PM Datasheet
Air Systems BB100-CO2PM Remote Alarms
Air Systems BB100-CO2PM Hoses & Fittings
Air Systems BB100-CO2PM Accessories
