FLIR ONE PRO LT iOS - Thermal Imaging Camera Attachment
FLIR ONE PRO LT iOS - Thermal Imaging Camera Attachment
FLIR ONE Pro LT has the power to find hidden problems faster than ever. With the enhanced resolution of FLIR VividIR, added perspective of FLIR MSX, and the convenience of the OneFit adjustable connector, FLIR ONE Pro LT works as hard as you do. Whether you're a professional or just focused on DIY projects, the FLIR ONE Pro LT has the powerful features you need at an affordable price.
Features
VIVIDIR IMAGE PROCESSING
Unique image-enhancement technology that sharpens thermals to help you catch potential problems early and reliably diagnose problems.
FLIR ONEFIT CONNECTOR
Adjustable connector extends by up to 4 mm, so you can secure your FLIR ONE®Pro LT to your mobile device while its still in the protective case.
HARD-WORKING APP
Work-based features such as multiple spot meters, level/span controls, and reporting through the FLIR Tools Mobile App support more professional problem-solving and functionality.
Specifications
Thermal Resolution: 80 × 60
Battery Life: Approximately 1 hr
Object Temperature Range: -20°C — 120°C (–4°F — 248°F)
Phone: Android (USB-C)
Accuracy: ±3°C or ±5%, typical Percent of the difference between ambient and scene temperature. Applicable 60 sec after start-up when the unit is within 15°C — 35°C and the scene is within 5°C — 120°C.
Operating Temperature: 0°C — 35°C (32°F — 95°F) , battery charging 0°C — 30°C (32°F — 86°F)
Spot Meter: Hottest, Coldest and 3 spot measurement
IMAGING & OPTICAL
Adjustable MSX distance: 0.3 m — Infinity
Focus: Fixed 15 cm — Infinity
Frame Rate: 8.7 Hz
General Description: Thermal and Visual Cameras with MSX
HFOV/VFOV: 50° ±1° / 38° ±1°
Palette: Gray (white hot), Hottest, Coldest, Iron, Contrast, Arctic, Lava and Color Wheel
Shutter: Automatic/Manual
Thermal Resolution: 80 × 60
Thermal Sensitivity/NETD: 100 mK
Thermal Sensor: Pixel size 17 µm, 8 — 14 µm spectral range
Video and Still Image Display/Capture: Saved as 1440 × 1080
Visual Resolution: 1440 × 1080
POWER
Battery charge time: 40 min
Battery Life: Approximately 1 hr
MEASUREMENT & ANALYSIS
Accuracy: ±3°C or ±5%, typical Percent of the difference between ambient and scene temperature. Applicable 60 sec after start-up when the unit is within 15°C — 35°C and the scene is within 5°C — 120°C.
Object Temperature Range: -20°C — 120°C (–4°F — 248°F)
Spot Meter: Hottest, Coldest and 3 spot measurement
GENERAL
Battery charge monitor: 0 — 100%
Dimensions (H x W x D): 68 × 34 × 14 mm (2.7 × 1.3 × 0.6 in)
Phone: Android (USB-C)
Weight: 36.5 g
ENVIRONMENTAL & CERTIFICATIONS
Certifications: MFi (iOS version), RoHS, CE/FCC, CEC-BC, EN61233
Drop test: Drop from 1.5m
Emissivity Settings: Matte: 95%, Semi-Matte: 80%, Semi-Glossy: 60%, Glossy: 30%
Non-Operating Temperature: -20°C — 60°C (-4°F — 140°F)
Operating Temperature: 0°C — 35°C (32°F — 95°F) , battery charging 0°C — 30°C (32°F — 86°F)
COMMUNICATION & DATA STORAGE
Capture modes: Video, Still image
Charging: Female USB-C (5V/1A)
File Formats: Still images – radiometric jpeg Video – MPEG-4 (MOV)
Video: Male USB-C
